Chillers

Mitsubishi Electric has manufactured chillers for over 40 years, and with the purchase of the Climaveneta brand, enhanced its product line-up and marked its full-scale entry into the chiller market. We offer both air source and water-cooled chillers for commercial buildings, spanning modular systems for scalable capacity through to a bespoke traditional range for comfort and process cooling applications.

- In this category

Modular Chiller Range

Connect several chillers together to provide increased capacity for both Chiller and Heat Pump operations, from kilowatt to megawatt operations. Our modular ranges can be applied to comfort, process and IT Cooling applications.

EACV / EAHV e-series Modular Chiller

The R32 e-series chiller range allows for up to 6 individual units to be connected together to provide a system capacity from 150kW to 1,080kW. Using this modular approach reduces space requirements and simplifies lifting and installation. Available as a cooling only or heat pump version.


Available in: 150kW – 1,080kW system capacity (up to 6 connected units)


Features:

  • Highly efficient inverter scroll compressors
  • Modular design to maximize space saving
  • Micro-channel aluminum heat exchange coil (cooling only)

- In this category

Traditional Chiller Range

Consisting of a wide range of models, the Climaveneta range of chillers are a new generation of air and water cooled chillers designed for comfort and process cooling applications. Most suited for commercial or industrial buildings, such as offices, shopping centers, hotels, health centers, banks and other similar buildings.

NX2 2 Compressor Air Cooled Chiller

Air-cooled chillers with scroll compressors designed to deliver the best efficiencies in comfort applications.


Available in: R410A refrigerant (43–221 kW), lower-GWP R454B refrigerant (40–208 kW)


  • Advanced technology for increased comfort and precision control
  • Scalable and fully customizable
  • Available in lower-GWP R454B refrigerant

NX2 4 Compressor Air Cooled Chillers

Air cooled chillers with scroll compressors designed to deliver the best efficiencies in comfort applications.


R410A refrigerant: 178 to 366 kW

Lower GWP R454B: 168 to 345 kW


  • Advanced technology for increased comfort and precision control
  • Scalable and fully customisable
  • Available in lower GWP R454B refrigerant

NX2 4-8 Compressor Air-Cooled Chillers

Air-cooled chillers with scroll compressors for optimal efficiency in comfort applications. The complete range is Eurovent-certified, and all sizes are fully ErP2021-compliant.


Capacity:  High Efficiency and High Efficiency plus Low Noise versions


  • Eurovent certified and fully ErP2021 compliant
  • High Efficiency and Low Noise versions available
  • Scalable and fully customisable

i-NX2-G07

New air source chillers and reversible heat pumps with variable-speed scroll compressors and R32 refrigerant. The i-NX2-N-G07 is optimised for comfort with high partial-load performance, a wide operating range, and low noise, while the i-NX2-G07 is designed for professional cooling such as process cooling.


Capacity: 50 to 220 kW, R32 refrigerant


  • Variable speed scroll compressors with low GWP R32 refrigerant
  • High performance at partial loads with a wide operating range
  • Low noise emissions, ideal for comfort applications
  • Fully accessible service points with extensive options

FX2 Screw Compressor Chillers

Air-cooled chillers with screw compressors for high-efficiency comfort applications, available in three refrigerant series with plate or shell-and-tube heat exchangers.


FX2-G01, R134a : 322 to 1,838 kW

FX2-G05, R513A: 322 to 1,838 kW

FX2-G04, R1234ze:  252 to 1,572 kW


  • Screw compressors for high-efficiency comfort cooling
  • Choice of standard, lower GWP, or near-zero GWP refrigerant
  • Plate or shell-and-tube heat exchanger options

i-FX2 Inverter Screw Chillers

The flagship platform of new-generation air source chillers with inverter-driven screw compressors, delivering considerable gains in seasonal efficiency, footprint, noise, and operating envelope, suitable for all comfort and process applications.


i-FX2, R134a:  380 to 1,859 kW

i-FX2, R513A:  380 to 1,859 kW

i-FX2, R1234ze:  380 to 1,859 kW


  • Inverter-driven screw compressors, the flagship chiller platform
  • Choice of standard, lower GWP or near-zero GWP refrigerant
  • Improved seasonal efficiency, reduced footprint and noise
